Ubiquiti G3 Reader - White
Notify Me When Available
Ubiquiti G3 Reader - White
Available:
Out of Stock
- Product SKU: UA-G3-W
- Category: All Things Ubiquiti, Best Selling Products, Building Security, Security Equipment
$332.00
Only 0 Ubiquiti G3 Reader - White Default Title left in stock.
The Ubiquiti G3 Reader White is a compact third-generation access reader with Apple Touch Pass support.
Mechanical
- Mechanical Dimensions: 93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4")
- Weight: 82 g (2.9 oz)
- Enclosure material: Polycarbonate, glass
- Mount material: Aluminum alloy
- Mounting: In wall, gang box
- Weatherproofing: IP55
Hardware
- Networking interface: (1) 10/100 MbE RJ45 port
- Connectivity: BLE 4.1, NFC
- Power method: PoE UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
- Supported voltage range: 48V DC
- Max. power consumption: 5W
- ESD/EMP protection: Air: ±15kV, contact: ±8kV
- Sensor: Proximity sensor
- Speaker: (1) 8 ohm, 0.7W
- LEDs: R/G/B/W
- Button: (1) Factory-reset
- NFC frequency: 13.56 MHz
- NFC read range: < 30 mm
- NFC technology: ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340), MIFARE Classic / MIFARE DESFIRE, Sony FeliCa™ (ID only), NFC Forum tags T1T, T2T, T3T, T4T and T5T, ECP 2.0
- Operating environment: Outdoor use
- Ambient operating temperature: Device: -30 to 45° C (-22 to 113° F)
- Ambient operating humidity: 5 to 90% noncondensing
- Software information: The software version of a product can be checked at https://unifi.ui.com
- UL 294 level: Destructive attack: Level I, Line security: Level I, Endurance: Level I, Standby power: Level I
- UL 294 statement: Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
- PoE cabling requirements: Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm 2 ) for patch cords; 24 AWG (0.21 mm 2 ) for horizontal or riser cable.
- CAN/ULC-60839-11-1 Grade: Grade assignment: I
- Certifications CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
- Document number, and issue date and/or revision level: UA-G3, V01
Software
- Management application: UniFi Access: Version 3.0.15 and later
The Ubiquiti G3 Reader White is a compact third-generation access reader with Apple Touch Pass support.
Mechanical
- Mechanical Dimensions: 93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4")
- Weight: 82 g (2.9 oz)
- Enclosure material: Polycarbonate, glass
- Mount material: Aluminum alloy
- Mounting: In wall, gang box
- Weatherproofing: IP55
Hardware
- Networking interface: (1) 10/100 MbE RJ45 port
- Connectivity: BLE 4.1, NFC
- Power method: PoE UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
- Supported voltage range: 48V DC
- Max. power consumption: 5W
- ESD/EMP protection: Air: ±15kV, contact: ±8kV
- Sensor: Proximity sensor
- Speaker: (1) 8 ohm, 0.7W
- LEDs: R/G/B/W
- Button: (1) Factory-reset
- NFC frequency: 13.56 MHz
- NFC read range: < 30 mm
- NFC technology: ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340), MIFARE Classic / MIFARE DESFIRE, Sony FeliCa™ (ID only), NFC Forum tags T1T, T2T, T3T, T4T and T5T, ECP 2.0
- Operating environment: Outdoor use
- Ambient operating temperature: Device: -30 to 45° C (-22 to 113° F)
- Ambient operating humidity: 5 to 90% noncondensing
- Software information: The software version of a product can be checked at https://unifi.ui.com
- UL 294 level: Destructive attack: Level I, Line security: Level I, Endurance: Level I, Standby power: Level I
- UL 294 statement: Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
- PoE cabling requirements: Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm 2 ) for patch cords; 24 AWG (0.21 mm 2 ) for horizontal or riser cable.
- CAN/ULC-60839-11-1 Grade: Grade assignment: I
- Certifications CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
- Document number, and issue date and/or revision level: UA-G3, V01
Software
- Management application: UniFi Access: Version 3.0.15 and later
